HPE ProLiant DL360 Gen11 Intel Xeon-S 4509Y 8-Core/ 32GB/8 SSF/MR408i-o (P70540-421



HPE ProLiant DL360 Gen11 Intel Xeon-S 4509Y 8-Core (2.60GHz 22.5MB) 32GB (1 x 32GB) PC5-5600B RDIMM 8 x Hot Plug 2.5in Small Form Factor x1 Tri-Mode Basic Carrier MR408i-o No Optical 1000W 3 Year Next Business Day Warranty

PROCESSOR

Processor manufacturer	Intel
Processor generation	Intel Xeon Scalable 4th Gen
Processor family	Intel Xeon Silver
Processor model	4509Y
Processor frequency	2.6 GHz
Processor cores	8
Processor cache	22.5 MB
Motherboard chipset	Intel C741
Number of processors installed	1
Maximum number of SMP processors	2



MEMORY

Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory layout (slots x size)	1 x 32 GB
ECC	YES
Maximum internal memory	8.19 TB
Memory slots	32x DIMM



STORAGE

Maximum storage capacity	153.6 TB
Total storage capacity	0 GB
HDD interface	SATA, Serial Attached SCSI (SAS)
Number of HDDs supported	8
Supported HDD sizes	2.5"
SSD interface	SATA, Serial Attached SCSI (SAS)
Supported SSD sizes	2.5"
Number of SSDs supported	8
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, 60
Optical drive type	No



GRAPHICS

On-board graphics card	YES
Maximum graphics card memory	16 MB



NETWORK

Ethernet interface type	Gigabit Ethernet
Ethernet LAN	Yes
LAN controller	Broadcom BCM5719



PORTS & INTERFACES

Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
VGA (D-Sub) ports quantity	1



DESIGN

Chassis type	Rack (1U)
Rack mounting	Yes



PERFORMANCE

Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Remote administration	iLO 6 ASIC



SOFTWARE

Operating system installed	NO
Compatible operating systems	Microsoft Windows Server VMware ESXi Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Canonical Ubuntu Oracle Linux and Oracle VM SAP Linux



OPERATIONAL CONDITIONS

Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	8 - 90%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3050 m
Non-operating altitude	0 - 9144 m



POWER

Power supply	1000 W
Redundant power supply (RPS) support	YES



WEIGHT & DIMENSIONS

Width	434.6 mm
Height	42.9 mm
Depth	753.1 mm
Weight	41.3 kg
